C610 Solved Mid Term Subjective
Question
These Questions Repeated plenty of time in Exams so After
learning Handout Please cast a glance on
these questions too…..
Question # 1
What
is the difference between LAN and WAN?
Answer
Local
area network (LAN)
LAN
is small in size covers the area within a room, building or cities.
Wide
area network (WAN)
WAN
is large in size and covers the area cities, countries and continents.
Question
# 2
Define
the term Jitter.
Answer
The
term Jitter is used for variance in transmission delays. Jitter is significance
for voice, video and data. Jitter can occur when a packet is delayed because
the network is busy.
Question
# 3
Give
a comparison of the following?
Thick
Ethernet wiring scheme and Thin Ethernet wiring scheme.
Answer
This
uses thick coax cable. AUI cable or transceiver or drop cable connects from NIC
to transceiver. AUI cable carries digital signal from NIC to transceiver. The
transceiver generates analog signal on coax cable. The wires in AUI carry
digital signals power and other control signals. Thick Ethernet also requires
terminators to avoid signal reflectance.
Thin
Ethernet uses thin coax cable that is cheaper and easier to install than thick
Ethernet coax. In thin Ethernet wiring scheme transceiver electronics are built
into NIC and NIC connect directly to network medium. Coax cable use connector
on NIC. Coax runs directly to back of each connected computer by T-connector.
The T-connector directly attaches to NIC.
Question # 4
WWW.VUSUPERIOR.NET
How
can Switched Virtual Network be established?
Answer:
Most networks offer dynamic
connections that last for a relatively short time. ATM can dynamically
establish a switched virtual circuit SVC that allows it as long as necessary
and then terminate it. The computer sends a connection request to the switch to
which it is attached. Software in the switch finds a path to the destination
and sends with the connection request. Each pair of switches in the path
communicates to choose a VPI/VCI for their tables. Once the connection is
established a message is given back to the originating computer to indicate the
SVC is ready.
Question # 5
Describe
permanent virtual circuits (PVC).
Answer
ATM
can provide the virtual circuits that look like traditional leased digital
circuits. The permanent virtual circuits PVC works as long as the customer pays
the periodic fee for its use. The forwarding table enter configured the terms
used by Telco Provisioning requires two steps.
To
determine a complete path.
To
choose appropriate VPI/VCI for each step in the path and configures each adjacent
pair of switches.
Question # 6
What
are default routes draw the table.
Answer
Routing
table entries can collapse with a default route. If destination doesn’t have in
explicit routing table entry and then it use a default route. It is shown in
the below table.
Destination
|
Next hop
|
Destination
|
Next hop
|
Destination
|
Next hop
|
Destination
|
Next hop
|
||
1
|
-
|
2
|
-
|
1
|
3,1
|
2
|
4,2
|
||
*
|
1,3
|
4
|
2,4
|
2
|
3,2
|
4
|
-
|
||
*
|
2,3
|
3
|
-
|
*
|
4,3
|
||||
4
|
3,4
|
||||||||
Node 1
|
Node 2
|
Node 3
|
Node 4
|
||||||
Question
# 7
WWW.VUSUPERIOR.NET
What
is the difference between the physical and logical topologies?
Answer:
Every LAN has a
topology, or the way that the devices on a network are arranged and how they
communicate with each other.
PHYSICL
TOPOLOGY:
The way that the
workstations are connected to the network through the actual cables that
transmit data -- the physical structure of the network -- is called the
physical topology. It depends on the wiring scheme.
LOGICAL
TOPOLOGY:
The
logical topology, in contrast, is the way that the signals act on the network
media, or the way that the data passes through the network from one device to
the next without regard to the physical interconnection of the devices. We can
say that it is defined by the specific network technology.
Question # 8
Define
Vector-Distance Algorithm.
Answer
Packet
switches wait for next update message and they iterate through entries in
message. If entry has shortest path to destination, insert source as next hop
to destination and record distance as distance from next hop to destination
plus distance from this switch to next hop.
Question
# 9
What
is the concept of store and forward technology?
Answer
STORE
AND FORWARD:
Data
delivery from one computer to another is accomplished through store and forward
technology. In this technology packet switch stores incoming packet and also
forwards that packet to another switch or computer. For this purpose packet
switch has internal memory into which it can hold packet if outgoing connection
is busy. Packets for each connection held on queue.
Question
# 10
How
can Switched Virtual Network be established?
Answer
SWITCHED
VIRTUAL CIRCUITS:
Most
networks offer dynamic connections, which last for a relatively short time.
To
handle this, ATM can dynamically establish a switched virtual circuit (SVC),
allow it last as long as necessary and then terminate it.
The
terminology comes from the Telco’s where switching system normally refers to
all switching.
ESTABLISHING
AN SVC:
The computer sends a
connection request to the switch to which it is attached.
Software in the
switch finds a network path to the destination and sends along the connection
request.
Each pair of switches
in the path communicates to choose a VPI/VCI for their tables. Once the
connection is established by the destination, a message is sent back to the
originating computer to indicate the SVC is ready.
If
any switch or the destination computer does not agree to setting up the VC, an
error message is sent back and the SVC is not established.
Question
# 11
How
can a bridge know whether to forward frames?
Answer
The bridge builds a
list of MAC addresses on either side of the bridge. Therefore, it knows which
packets should be forwarded to the other side and which should not. Most
bridges are self-learning bridges. As soon as a frame arrives to a bridge, it
extracts a source address from its header and automatically adds it in the list
for that segment. In this way a bridge builds up address lists.
In the example of a
packet that uses a MAC address not in its table it can err on the side of
caution by forwarding the packet.
Question # 12
Compare
connection oriented and connectionless Service.
Answer
Connection-Oriented
vs. Connectionless Service
This characteristic
specifies whether conversations take place in a more or less structured manner.
When using a connection-oriented protocol, you incur the overhead of
setting up a virtual circuit (a defined communications path) between the sender
and receiver, which is maintained until the sender and receiver have completed
their entire conversation.
When the conversation
is completed, you incur the overhead of tearing down the virtual circuit.
Connection-oriented protocols provide guaranteed delivery of messages in the
order in which they were sent.
Contrast
this with Connectionless service, which does not require establishing a
session and a virtual circuit. This can be found in the network layer or
transport layer, depending on the protocol. You can think of a connectionless
protocol as being akin to mailing a post card. You send it and hope that the
receiver gets it. Common features of a connectionless service are:
·
Packets do not need to arrive in a specific order
·
Reassembly
of any packet broken into fragments during transmission must be in
proper order.
·
No time is used in creating a session
·
No Acknowledgement is required.
·
The largest connectionless network in use today is the Internet
Question # 13
Which
type of information is obtained from network sniffer and in which mode Network
sniffer operates?
Answer:
A
network analyzer also called network monitor or a network sniffer is used to
examine the performance of or debug a network. It can report statistics such as
capacity utilization, distribution of frame size, collision rate or token
circulation time
Most
installations still use DIX Ethernet encoding in which there is no LLC/SNAP
header in the frame. A network analyzer can tell from the values in the type
field (small values are lengths, which mean an LLC/SNAP header is located in
the first octets of the data area; large values are types, which mean no
LLC/SNAP header is included).
The
operation of network analyzer is a computer with a network interface that
receives all frames, which is called promiscuous mode. So many desktop
computers have interface that can be configured for promiscuous mode. When
combined with software computer can examine any frame on LAN. In this way the
communication across LAN is guaranteed to be private. Computer receives and
displays frames on the LAN.
Network
analyzer can be configured to filter and process frames. It can count frames of
specific type of size. It displays only frames from or to specific computers.
Question # 14
Differentiate b/w Thin
Ethernet, Thick Ethernet and Twisted Pair Ethernet?
Answer
Thick
Ethernet:
Thick
Ethernet, officially known as 10 Base-5, is the oldest form of Ethernet.
One
form of cabling supported by Ethernet is low-loss 50 Ohm coaxial cable as shown
in the figure below. This type of cable is 0.5" diameter (usually supplied
with a yellow outer PVC coating) and rather inflexible. It has become known in
the communications industry as "Thick Ethernet". The official name
for this cable is 10 Baseband5 (10B5), indicating that it is specified for
baseband communications at 10 Mbps over distances up to 500m.
Thin Ethernet:
Thin Ethernet, officially called 10 Base-2, is a less expensive version of 10 Base-5 (Thick Ethernet) technologies. It uses a lighter and thinner coaxial cable and dispenses with the external transceivers used with 10 Base-5.
Thin Ethernet, officially called 10 Base-2, is a less expensive version of 10 Base-5 (Thick Ethernet) technologies. It uses a lighter and thinner coaxial cable and dispenses with the external transceivers used with 10 Base-5.
10 Base-2 uses an
RG-58A/U coaxial cable and is wired in a bus topology. Each device on the
network is connected to the bus through a BNC "T" adapter, and each
end of the bus must have a 50 Ohm terminator attached. Each node on the bus
must be a minimum of 0.5 meters (1.5 feet) apart, and the overall length of the
bus must be less than 185 meters (606 feet).
Twisted
Pair Ethernet:
Twisted Pair Ethernet
(10baseT), sometime also called "UTP" from "Unshielded Twisted
Pair", is based on using a cable similar to phone-wiring. The cable is
connected via RJ-45 connectors to the network card installed in the PC.
Question
# 15
LIST
SOME CHARACTERISTICS OF A CLIENT?
Answer
The characteristics
of a client are explained below:
"Client is an
arbitrary application program.
"It becomes
client temporarily.
"It can also
perform other computations.
"It is invoked
directly by the user.
"It runs locally
on the user’s computer.
"It actively
initiates contact with a server.
"It contacts one
server at a time.
Question # 16
Explain
TCP Segment Format?
Answer
TCP uses single
format for all messages. TCP uses the term segment to refer to a message. Each
message sent from TCP on one machine to TCP on another machine uses this format
including data and acknowledgement.
Question # 17
What
is IPv6 Address Notation?
Answer:
128-bit addresses
unwidely in dotted decimal; requires 16 numbers:
105.220.136.100.255.255.255.255.0.0.18.128.140.10.255.255
69DC: 8864: FFFF:
FFFF: 0:1280:8C0A: FFFF
Zero-compression –
series of zeroes indicated by two colons
FF0C: 0:0:0:0:0:0:B1
FF0C::B1
IPv6 address with 96
leading zeros is interpreted to hold an IPv4 address
Question # 18
How
much data can present on original Ethernet segment at one time? To find out
compute the delay-throughput product. The original Ethernet operate at 10 mega
bits per second, and a segment was limited to 500 meters. Assume the signals
propagate down the cable at 66 percent of the speed of light?
Answer
Speed of light = 299 792
458 m / s
Bandwidth=10
Delay = 66 percent of
speed of light =197863022 m/s
Bandwidth Delay
product= 247328777500
Question
# 19
Explain
these terms
Star
topology, Ring topology, Frame?
Answer
FRAME:
A
frame or hardware frame denotes a packet of a specific format on a specific
hardware technology
RING TOPOLOGY
In
this topology of network the computers are connected to each other in closed
loop.
STAR TOPOLOGY
In this topology, all computers are attached to
a central point, which is sometimes
called the Hub
Question # 20
Explain the term bridge and
its functions
Answer
A bridge keeps a list for each segment that
consists of physical addresses of the computer attached to that segment. In
this way a bridge knows on which segment a destination computer is attached.
Most bridges are self learning bridges. As soon
as a frame arrives to a bridge, it extracts a source address from its header
and automatically adds it in the list for that segment. In this way a bridge
builds up address lists.
A bridge is a hardware device also used to
connect two LAN segments to extend a LAN.
FRAME FILTERING
The most important task a bridge performs is
frame filtering. If both the source and destination are on the same segment, it
does not forward the frame to the other segment. A frame is forwarded to the
other segment, if it is destined to that segment.
Question # 21
Explain NIC and Computer
Processing?
Answer
NIC AND CPU PRCESSING:
NIC contains sufficient hardware to process data
independent of system CPU. In which some NICs contain separate microprocessor.
In addition to this it also include analog circuitry interface to system bus,
buffering and processing
Question # 22
What is Parity Checking? Explain
Answer
Parity checking
To detect the error there are different schemes
for which parity checking is also common used, in parity checking, parity
refers to the number of bits set to 1 in the data item. A parity bit is an
extra bit transmitted with data item chose to give the resulting bit even or odd parity.
Question # 23
What do you know about Djikstra’s algorithm?
Answer:
Djikstra’s algorithm
Djikstra’s
algorithm can accommodate weights on edges in graph. The shortest path is then
the path with lowest total weight.
Question # 24
What are the uses of Repeater?
Answer
Repeater
is a networking device
A repeater is used to increase the signal
strength. It amplifies the weakening signal received from one segment and then
retransmits onto another segment.
WWW.VUSUPERIOR.NET
Wish u Best of Luck
Remember me in your prayers
Students jab tak hum hain tab tak moj krain;) :P
ReplyDelete
